50 TON DOUBLE GIRDER PORTAL CRANE (INCOMPLETE)

CRANE INFORMATION

CRANE MANUFACTURE: CONDRA

CRANE MODEL: W/O 5152

CRANE TYPE: OVERHEAD

CRANE OPERATING AREA: OUTDOOR

CRANE DRAWING NUMBER: 49-14-20

CRANE DRAWN BY: VLADO

CRANE DRAWN DATE: 17-04-03

CRANE GIRDER INFORMATION

CRANE GIRDER PART NUMBER: 49-14-21

CRANE GIRDER DESCRIPTION: BOX 800/20/20

CRANE GIRDER MASS: 6650 KG

CRANE END/C SET INFORMATION

CRANE END/C SET PART NUMBER: 49-14-22

CRANE END/C SET DESCRIPTION: Ø630

CRANE END/C SET MASS: 2450 KG

CRANE L.T WHEEL ASSY INFORMATION

CRANE L.T WHEEL ASSY PART NUMBER: 01-29-51

CRANE L.T WHEEL ASSY DESCRIPTION: Ø630

CRANE L.T WHEEL ASSY MASS: 1250 KG

CRANE PIER LEG INFORMATION

CRANE PIER LEG PART NUMBER: 49-14-25

CRANE PIER LEG DESCRIPTION: SET

CRANE PIER LEG MASS: 1700 KG

CRANE SHEAR LEG INFORMATION

CRANE SHEAR LEG PART NUMBER: 49-14-26

CRANE SHEAR LEG DESCRIPTION: SET

CRANE SHEAR LEG MASS: 840 KG

CRANE PLATFORM INFORMATION

CRANE PLATFORM PART NUMBER: 49-14-28

CRANE PLATFORM DESCRIPTION: FULL LENGTH

CRANE PLATFORM MASS: 500 KG

CRANE LADDER INFORMATION

CRANE LADDER PART NUMBER: 49-14-29

CRANE LADDER DESCRIPTION: CAT LADDER

CRANE LADDER MASS: 550 KG
